The DASnet™ Rack99 is a power, signal and data distribution system assembled in a rugged 8-unit rack. Is composed of three elements: Distro Racknet 32_9 of 32A, DASnet™ Patch Power 9 and DASnet™ Matrix 99.
The Distro Racknet 32_9 is a three-phase power distributor consisting of three-phase input and output connectors, automatic circuit breakers per phase and single-phase output connectors. The DASnet™ Patch Power 9 provides AC power up to 9 connected devices into the system, in a simple and safe way. The DASnet™ Matrix 99 distribution module routes 9 balanced audio channels and DASnet™ monitoring data up to 9 zones or clusters with powered D.A.S. systems.
Specifications
| Brands | D.A.S. |
|---|
| Electronics and Connectors | |
| Power Distro Type | Distro Racknet 32A/400 V |
| Protections | 1 x RCD 40 A/30 mA/4P 9 x MCB 16 A/C/1P |
| Connectors | AC In: 32 A/CEE/400 V/5P AC Thru: 32A/CEE/400 V/5P AC Out: 9 x 16 A Shuko+Aux Audio In: 9 x Female XLR Audio Out: 2 x Male XLR/9 Rear DASnet In: Female XLR DASnet Out: Male XLR etherCON Out: 9 Audio Link: 8 |
| Dimensions-Weight | |
| Rack size | 8 Units |
| Dimensions ( H x W x D ) | 720 x 550 x 425 mm 28,3 x 21,6 x 16,7 in |
| Net Weight | 33,2 kg ( 73,2 lb ) |
| Shipping | |
| Shipping Weight | 0,0 kg ( 0,0 lb ) |
